Product Description
Valve Type: Flat Face
Coupling Style: Screw to Connect
Connection Style: 1-1/16 x 12 ORB Female
ISO Number:
Material: Carbon Steel
Surface Finish: Zinc-Nickel
Working Pressure: 5500 PSI
Flow Rate: 17.5 US GPM (66 L/min)
Working Temperature: -40°C to 121°C
Connect Under Pressure: Yes
Compatible with part numbers: 6100068616, HDFFN1/2X3/4ORBM, HFT12-M-12S, Q-HFT-08N-12RF-Z, QFSI-08-12R-M, QRC-FT-12-M-U12-BT-W3, VEP4OF6
Product Videos
Custom Field
UOM EA
Configuration HFT Series
Shape Nipple
Combination Nipple X Female
Thread Type 1 Body Size
Thread Type 2 ORB
Thread Size 1 Dash 08 Body
Thread Size 2 Dash 12 - 1 1/16 x 14
Material Carbon Steel
