Code 62 Adapters

-08 CODE 62 CLAMP KIT

Kit includes: 2 – Flange halves 4 – Grade 8 hex head cap screws 4 – Hardened flat washers 1 – Nitrile O-ring Thread type: Code 62 flange Thread: 1/2"

-08 CODE 62 FLANGE CAP

Pad size: .500 in A: 1.94 in B: 2.30 in C: .718 in D: 1.594 in E: 1.25 in F: 1.000 in O-ring: -08 SAE Mounting hardware: 5/16-18x2.00

-08 CODE 62 FLANGE PLUG

Connection type: Flange plug Flange size: 1/2” Standard: SAE J518 Role: Flange connection Material: Trivalent zinc plated carbon steel Working pressure: 5000 psi Burst ratio: 4:1 Temperature range: -54°C to 260°C (-65°F to...

-08 CODE 62 MALE X -08 JIC MALE

Connection type 1: Split flange head Flange size: 1/2” Standard: SAE J518 Role: Flange connection Connection type 2: Male JIC Tube OD: 1/2" Thread type: 3/4-16 UNF Standard: SAE J514 – Class 2A thread Role: Line/tube connection Material:...

-08 CODE 62 MALE X -08 JIC MALE 90°

Connection type 1: Split flange head Flange size: 1/2” Standard: SAE J518 Role: Flange connection Connection type 2: Male JIC Tube OD: 1/2" Thread type: 3/4-16 UNF Standard: SAE J514 – Class 2A thread Role: Line/tube connection Material:...

-08 CODE 62 MALE X -08 ORFS MALE

Connection type 1: Male ORFS Tube OD: 1/2" Thread type: 13/16-16 UN Standard: SAE J1453 – Class 2A thread Role: Line/tube connection Connection type 2: Split flange head Flange size: 1/2" Standard: SAE J518 Role: Flange connection Material:...

-08 CODE 62 MALE X -12 ORFS MALE 90°

Tube OD: .750” Flange size: 1/2" Thread: 1-3/16-12

-12 CODE 61 MALE X -16 ORFS MALE 90°

Tube OD: 1” Flange size: 3/4" Thread: 1-7/16-12

-12 CODE 62 CLAMP KIT

Kit includes: 2 – Flange halves 4 – Grade 8 hex head cap screws 4 – Hardened flat washers 1 – Nitrile O-ring Thread type: Code 62 flange Thread: 3/4”

-12 CODE 62 FLANGE CAP

Pad size: .750 in A: 2.50 in B: 2.95 in C: .937 in D: 2.000 in E: 1.25 in F: 1.000 in O-ring: -12 SAE Mounting hardware: 3/8-16x2.00

-12 CODE 62 FLANGE PLUG

Connection type: Flange plug Flange size: 3/4” Standard: SAE J518 Role: Flange connection Material: Trivalent zinc plated carbon steel Working pressure: 6000 psi Burst ratio: 4:1 Temperature range: -54°C to 260°C (-65°F to...

-12 CODE 62 MALE X -12 JIC MALE

Connection type 1: Split flange head Flange size: 3/4” Standard: SAE J518 Role: Flange connection Connection type 2: Male JIC Tube OD: 3/4" Thread type: 1-1/16-12 UN Standard: SAE J514 – Class 2A thread Role: Line/tube connection Material:...
