Product Description
RK Series Quick Release Coupler Fxed Half Group 3 x DIN Male 16S
Valve Type: Flat Face
Coupling Style: Screw to Connect
Connection Style: 24 x 1.5 DIN Male
ISO Number:
Material: Carbon Steel
Surface Finish: Zinc-Nickel
Working Pressure: 6092 PSI
Flow Rate: 23.78 US GPM (90 L/min)
Working Temperature: -40°C to 121°C
Connect Under Pressure: Yes
Compatible with part numbers: 2014901797, 402603, Q-RK-16S-F-3, Q-VS-16S-F-3, QRC-RH-12F-16S-S1-W3, QS-TCH-16F-F-3
Product Videos
Custom Field
UOM EA
Configuration RK Series
Combination Male X Male
Thread Type 1 Body Size
Thread Type 2 DIN
Thread Size 1 Dash 03 Body
Thread Size 2 Tube 16S - M24 x 1.5
Material Carbon Steel
