Product Description
Code 62 Flat Socket Weld - Tube
Part No. Flat Face Fig. 2: W63-20-16
Tube Size: 1.25 Pad Size: 1.00 A: 2.75 B: 3.19 C: 1.093 D: 2.250 E: 1.500
F: .630 G: 1.560 H: 1.000 J: 1.252 K: .492 L: 7/16-14
Mounting Hardware
O-Ring: 219 SHCS: 7/16-14X2.50
TUBE 1 X CODE 62 FEMALE 1-1/4 BRAZE-ON FLANGE
Compatible with the following part numbers: W63-20-16
Product Videos
Custom Field
UOM EA
SKU Volume 0
Configuration Female X Female
Shape Straight
Combination TUBE X Flange
Thread Type 1 Tube
Thread Type 2 Flange - Code 62
Thread Size 1 Dash 16 - 1
Thread Size 2 Dash 20 - 1 1/4
Material Carbon Steel
