Product Description
Code 62 Flat Socket Weld - Tube
Part No. Flat Face Fig. 2: W63-36-32
Tube Size: 2.25 Pad Size: 2.00 A: 4.50 B: 5.25 C: 1.750 D: 3.812 E: 1.750
F: .875 G: 2.490 H: 2.00 J: 2.252 K: .781 L: 3/4-10
Mounting Hardware
O-Ring: 228 SHCS: 3/4-10X3.00
TUBE 2 X CODE 62 FEMALE 2-1/4 BRAZE-ON FLANGE
Compatible with the following part numbers: W63-36-32
Product Videos
Custom Field
UOM EA
SKU Volume 0
Configuration Female X Female
Shape Straight
Combination TUBE X Flange
Thread Type 1 Tube
Thread Type 2 Flange - Code 62
Thread Size 1 Dash 32 - 2
Thread Size 2 Dash 36 - 2 1/4
Material Carbon Steel
