TUBE 2 X CODE 62 FEMALE 2 BRAZE-ON

SKU:

A-2S92-3232

Shipping:

Calculated at Checkout

UOM:

SKU Volume:

Configuration:

Female X Female

Shape:

Straight

Combination:

TUBE X Flange

Thread Type 1:

Tube

Thread Type 2:

Flange - Code 62

Thread Size 1:

Dash 32 - 2

Thread Size 2:

Dash 32 - 2

Material:

Carbon Steel

Code 62 Flat Socket Weld - Tube

Part No. Flat Face Fig. 2: W63-28-28

Tube Size: 2.00 Pad Size: 2.00 A: 4.50 B: 5.25 C: 1.750 D: 3.812 E: 1.750

F: .875 G: 2.490 H: 1.875 J: 2.002 K: .781 L: 3/4-10

Mounting Hardware

O-Ring: 228 SHCS: 3/4-10X3.00

TUBE 2 X CODE 62 FEMALE 2 BRAZE-ON FLANGE

Compatible with the following part numbers: W63-32-32

UOM EA

SKU Volume 0

Configuration Female X Female

Shape Straight

Combination TUBE X Flange

Thread Type 1 Tube

Thread Type 2 Flange - Code 62

Thread Size 1 Dash 32 - 2

Thread Size 2 Dash 32 - 2

Material Carbon Steel
