Product Description
Valve Type: Flat Valve
Coupling Style: Screw to Connect
Connection Style: 3/4 x 14 NPT Female
ISO Number:
Material: Brass and Carbon Steel
Surface Finish: Zinc-Plating and Thick-Film-Passivation
Working Pressure: 3000 PSI
Flow Rate: 35 US GPM (132 L/min)
Working Temperature: -25°C to 100°C
Connect Under Pressure: Under Residual Pressure
Compatible with part numbers: 6100161791, 61152, 6WF6-B, B-QC-2500-12-12, C501-12, FB3/4F, FST FB12/34NPT-F5, QD-BTTWC12-12F, QFB-12F,
QRC-HM-19-F-NF12-BT-W162AA, WSC19-F-12N, WTF12-WN12
Product Videos
Custom Field
UOM EA
SKU Volume 0
Configuration WS Series
Shape Coupler
Thread Type 1 Body Size
Thread Type 2 NPT
Thread Size 1 Dash 12 Body
Thread Size 2 Dash 12 - 3/4 x 14
Material Carbon Steel
