Adapters

-02 BSPT MALE X -04 BSPP MALE

BSPT: 1/8-28 Pipe size: 1/8” Standard: ISO 7-1 Role: Line/pipe connection BSPP: 1/4-19 Standard: ISO 8434-6 ISO 1179 Role: Line/port connection Working pressure: 5100 psi Burst ratio:

-02 BSPT MALE X -04 JIC MALE

BSPT: 1/8-28 Pipe size: 1/8” Standard: ISO 7-1 Role: Line/pipe connection JIC: 7/16-20 UNF Tube size: 1/4" Standard: SAE J514 class 2A thread Role: Line/tube connection Working pressure:

-02 BSPT MALE X -04 JIC MALE 45°

Hex size: 10.5mm BSPT: 1/8-28 JIC: 7/16-20 L1: 16mm L2: 10.5mm Minimum bore: 4.5mm Material: Steel

-02 BSPT MALE X -04 JIC MALE 90°

BSPT: 1/8-28 JIC: 7/16-20 L1: 10.5mm L2: 16mm Minimum bore: 4.5mm Material: Steel

-02 BSPT MALE X 04LL DIN MALE

BSPT: 1/8-28 DIN: M8 X 1 L1: 8mm L2: 8mm Minimum bore: 3mm Material: Steel

-02 BSPT MALE X 04LL DIN MALE 90°

BSPT: 1/8-28 DIN: M8 X 1 Material: Steel

-02 BSPT MALE X 06L DIN MALE 90°

BSPT: 1/8-28 DIN: M12 X 1.5 Material: Steel

-02 BSPT MALE X 06LL DIN MALE

BSPT: 1/8-28 DIN: M10 X 1 L1: 8mm L2: 8mm Minimum bore: 4.5mm Material: Steel

-02 BSPT MALE X 06LL DIN MALE 90°

BSPT: 1/8-28 DIN: M10 X 1 Material: Steel

-02 BSPT MALE X 08L DIN MALE

BSPT: 1/8-28 DIN: M14 X 1.5 L1: 10.5mm L2: 10.5mm Minimum bore: 4.5mm Material: Steel

-02 JIC CAP

Thread: 5/16-24 Material: Carbon steel

-02 JIC HEX PLUG

JIC: 5/16-24 Material: Carbon steel
