BSP Elbows

-02 BSPT MALE X 06LL DIN MALE 90°

BSPT: 1/8-28 DIN: M10 X 1 Material: Steel

-04 BSPP ADJUSTABLE MALE ORR X -04 JIC MALE 90°

Connection type: Male BSPP adjustable ORR Thread type: 1/4-19 Standard: ISO 1179 Role: Port connection Connection type: Male JIC Tube OD: 1/4" Thread type: 7/16-20 UNF Standard: SAE J514 Class 2A thread Role: Line/tube connection Material: Trivalent zinc...

-04 BSPP ADJUSTABLE MALE ORR X -05 JIC MALE 90°

Connection type: Male BSPP adjustable ORR Thread type: 1/4-19 Standard: ISO 1179 Role: Port connection Connection type: Male JIC Tube OD: 5/16" Thread type: 1/2-20 UNF Standard: SAE J514 Class 2A thread Role: Line/tube connection Material: Trivalent zinc...

-04 BSPP ADJUSTABLE MALE ORR X -06 JIC MALE 90°

Connection type: Male BSPP adjustable ORR Thread type: 1/4-19 Standard: ISO 1179 Role: Port connection Connection type: Male JIC Tube OD: 3/8" Thread type: 9/16-18 UNF Standard: SAE J514 Class 2A thread Role: Line/tube connection Material: Trivalent zinc...

-04 BSPP ADJUSTABLE MALE ORR X -08 JIC MALE 90°

Connection type: Male BSPP adjustable ORR Thread type: 1/4-19 Standard: ISO 1179 Role: Port connection Connection type: Male JIC Tube OD: 1/2" Thread type: 3/4-16 UNF Standard: SAE J514 Class 2A thread Role: Line/tube connection Material: Trivalent zinc...

-04 BSPP ADJUSTABLE ORR MALE X -04 ORFS MALE 90°

BSPP: 1/4-19 Standard: ISO 1179 Role: Port connection ORFS: 9/16-18 UNF Tube OD: 1/4" Standard: SAE J1453 Class A thread Role: Line/tube connection Material: Trivalent zinc plated steel Seal material: Buna-N (nitrile) Working pressure: 4000 psi Burst...

-04 BSPP ADJUSTABLE ORR MALE X -06 ORFS MALE 90°

BSPP: 1/4-19 Standard: ISO 1179 Role: Port connection ORFS: 11/16-16 UNF Tube OD: 3/8" Standard: SAE J1453 Class A thread Role: Line/tube connection Material: Trivalent zinc plated steel Seal material: Buna-N (nitrile) Working pressure: 4000 psi Burst...

-04 BSPP ELASTOMER SEAL BANJO MALE X 06S DIN MALE 90°

BSPP: 1/4-19 DIN: M14 x 1.5 Material: Carbon steel body, Buna-N (nitrile) seal Pressure size/tube rating: Heavy duty

-04 BSPP ELASTOMER SEAL BANJO MALE X 08L DIN MALE 90°

BSPP: 1/4-19 DIN: M14 x 1.5 Material: Carbon steel body, Buna-N (nitrile) seal Pressure size/tube rating: Light duty

-04 BSPP ELASTOMER SEAL BANJO MALE X 08S DIN MALE 90°

BSPP: 1/4-19 DIN: M16 x 1.5 Material: Carbon steel body, Buna-N (nitrile) seal Pressure size/tube rating: Heavy duty

-04 BSPP ELASTOMER SEAL BANJO MALE X 10L DIN MALE 90°

BSPP: 1/4-19 DIN: M16 x 1.5 Material: Carbon steel body, Buna-N (nitrile) seal Pressure size/tube rating: Light duty

-04 BSPP FEMALE X -04 BSPP FEMALE 90° SWIVEL

BSPP 1 & 2: 1/4-19 L1: 36mm Minimum bore: 5mm Material: Steel
