Product Description
Barrel connector: Female NPT
Barrel connector size: -08 (1/2”)
Stem connector: Male NPT
Stem connector size: -08 (1/2”)
T1: 1/2-14 (NPSM)
T2: 1/2-14 (NPTF)
A: 2.83” (71.9 mm)
B: 1.99” (50.5mm)
C: 2.29” (58.2mm)
D: 1.64” (41.7mm)
H hex: 1.13” (28.7mm)
J hex: 1” (25.4mm)
L hex: 1” (25.4mm)
K diameter: 1.3 (33mm)
Vacuum: 29.5”/Hg (1 bar)
Temperature range: -30°F to 250°F (-34°C to 121°C)
Max working pressure: 5000 psi (34.5 MPa)
Product Videos
Custom Field
UOM EA
Shape 90
Combination NPT X NPSM
Thread Type 1 NPT
Thread Type 2 NPSM
Thread Size 1 Dash 08 - 1/2 x 14
Thread Size 2 Dash 08 - 1/2 x 14
