  • -16 CODE 61 MALE X -20 JIC MALE 90° TUBE
  • -16 CODE 61 MALE X -20 JIC MALE 90° TUBE
  • -16 CODE 61 MALE X -20 JIC MALE 90° TUBE
  • -16 CODE 61 MALE X -20 JIC MALE 90° TUBE

    • -16 CODE 61 MALE X -20 JIC MALE 90° TUBE

    (No reviews yet) Write a Review
    SKU:
    A-SJ18-1620-T
    Shipping:
    Calculated at Checkout
    UOM:
    EA
    SKU Volume:
    0
    Configuration:
    Male X Male
    Shape:
    90
    Combination:
    Flange X JIC
    Thread Type 1:
    Flange - Code 61
    Thread Type 2:
    JIC
    Thread Size 1:
    Dash 16 - 1
    Thread Size 2:
    Dash 20 - 1 5/8 x 12
    Material:
    Carbon Steel

    Product Description

    Connection type 1: Split flange head

    Flange size: 1"

    Standard: SAE J518

    Role: Flange connection

    Connection type 2: Male JIC

    Tube OD: 1-1/4"

    Thread type: 1-5/8-12 UN

    Standard: SAE J514 Class 2A thread

    Role: Line/tube connection

    Material: Trivalent zinc plated steel

    Working pressure: 4000 psi

    Burst ratio: 4:1

    Temperature range: -54°C to 260°C (-65°F to 500°F)

    Product Videos

    Custom Field

    UOM EA
    SKU Volume 0
    Configuration Male X Male
    Shape 90
    Combination Flange X JIC
    Thread Type 1 Flange - Code 61
    Thread Type 2 JIC
    Thread Size 1 Dash 16 - 1
    Thread Size 2 Dash 20 - 1 5/8 x 12
    Material Carbon Steel
