Adapters

-12 BSP MALE X -10 ORB MALE

BSP: 3/4-14 ORB: 7/8-14 Material: Carbon steel body, Buna-N (nitrile) seal

-12 BSP MALE X -12 BSP FLAT FACE MALE CONVERTER

BSPP: 3/4-14 Material: Carbon steel body, Buna-N (nitrile) seal

-12 BSP MALE X -12 ORB MALE

BSP: 3/4-14 ORB: 1-1/16-14 Material: Carbon steel body, Buna-N (nitrile) seal

-12 BSP MALE X -16 ORB MALE

BSP: 3/4-14 ORB: 1-5/16-12 Material: Carbon steel body, Buna-N (nitrile) seal

-12 BSP/BSPP ELASTOMER SEAL X -06 JIC MALE

BSPP: 3/4-14 JIC: 9/16-18 Material: Carbon steel body, Buna-N (nitrile) seal

-12 BSP/BSPP ELASTOMER SEAL X -08 JIC MALE

BSPP: 3/4-14 JIC: 3/4-16 Material: Carbon steel body, Buna-N (nitrile) seal

-12 BSP/BSPP ELASTOMER SEAL X -10 JIC MALE

BSPP: 3/4-14 JIC: 7/8-14 Material: Carbon steel body, Buna-N (nitrile) seal

-12 BSP/BSPP ELASTOMER SEAL X -12 JIC MALE

BSPP: 3/4-14 JIC: 1-1/16-12 Material: Carbon steel body, Buna-N (nitrile) seal

-12 BSP/BSPP ELASTOMER SEAL X -16 JIC MALE

BSPP: 3/4-14 JIC: 1-5/16-12 Material: Carbon steel body, Buna-N (nitrile) seal

-12 BSPP ADJUSTABLE MALE ORR X -08 JIC MALE 90°

Connection type: Male BSPP adjustable ORR Thread type: 3/4-14 Standard: ISO 1179 Role: Port connection Connection type: Male JIC Tube OD: 1/2" Thread type: 3/4-16 UNF Standard: SAE J514 Class 2A thread Role: Line/tube connection Material: Trivalent zinc...

-12 BSPP ADJUSTABLE MALE ORR X -10 JIC MALE 90°

Connection type: Male BSPP adjustable ORR Thread type: 3/4-14 Standard: ISO 1179 Role: Port connection Connection type: Male JIC Tube OD: 5/8" Thread type: 7/8-14 UNF Standard: SAE J514 Class 2A thread Role: Line/tube connection Material: Trivalent zinc...

-12 BSPP ADJUSTABLE MALE ORR X -12 JIC MALE 90°

Connection type: Male BSPP adjustable ORR Thread type: 3/4-14 Standard: ISO 1179 Role: Port connection Connection type: Male JIC Tube OD: 3/4" Thread type: 1/2-20 UNF Standard: SAE J514 Class 2A thread Role: Line/tube connection Material: Trivalent zinc...
