-20 CAT STYLE SPLIT FLANGE KIT

Includes: (2) split flange halves, (4) hex head bolts and flat washers. Material: Carbon steel Flange size: 1-1/4” A: 3.75 in (95.3mm) B: 2.625 in (66.7mm) C: 0.585 in (14.9mm) D: 1.490 in (37.8mm) E: 0.531 in (13.5mm) F: 1.705 in (43.3mm) G: 2.134...

-20 CODE 61 CLAMP KIT

Kit includes: 2 – Flange halves 4 – Grade 8 hex head cap screws 4 – Hardened flat washers 1 – Nitrile O-ring Thread type: Code 61 flange Thread: 1-1/4”

-20 CODE 61 FLANGE PLUG

Connection type: Flange plug Flange size: 1-1/4” Standard: SAE J518 Role: Flange connection Material: Trivalent zinc plated carbon steel Working pressure: 4000 psi Burst ratio: 4:1 Temperature range: -54°C to 260°C (-65°F to...

-20 CODE 61 MALE X -12 JIC MALE

Connection type 1: Split flange head Flange size: 1-1/4” Standard: SAE J518 Role: Flange connection Connection type 2: Male JIC Tube OD: 3/4" Thread type: 1-1/16-12 UN Standard: SAE J514 – Class 2A thread Role: Line/tube connection Material:...

-20 CODE 61 MALE X -12 JIC MALE 90°

Connection type 1: Split flange head Flange size: 1-1/4" Standard: SAE J518 Role: Flange connection Connection type 2: Male JIC Tube OD: 3/4" Thread type: 1-1/16-12 UN Standard: SAE J514 Class 2A thread Role: Line/tube connection Material: Trivalent zinc...

-20 CODE 61 MALE X -16 JIC MALE

Connection type 1: Split flange head Flange size: 1-1/4” Standard: SAE J518 Role: Flange connection Connection type 2: Male JIC Tube OD: 1" Thread type: 1-5/16-12 UN Standard: SAE J514 – Class 2A thread Role: Line/tube connection Material:...

-20 CODE 61 MALE X -16 JIC MALE 90°

Connection type 1: Split flange head Flange size: 1-1/4" Standard: SAE J518 Role: Flange connection Connection type 2: Male JIC Tube OD: 1" Thread type: 1-5/16-12 UN Standard: SAE J514 Class 2A thread Role: Line/tube connection Material: Trivalent zinc...

-20 CODE 61 MALE X -16 JIC MALE 90° TUBE

Connection type 1: Split flange head Flange size: 1-1/4" Standard: SAE J518 Role: Flange connection Connection type 2: Male JIC Tube OD: 1" Thread type: 1-5/16-12 UN Standard: SAE J514 Class 2A thread Role: Line/tube connection Material: Trivalent zinc...

-20 CODE 61 MALE X -16 ORFS MALE

Connection type: Male ORFS Tube OD: 1-1/4" Thread type: 1-11/16-12 UN Standard: SAE J1453 – Class 2A thread Role: Line/tube connection Connection type: Split flange head Flange size: 1" Standard: SAE J518 Role: Flange connection Material: Trivalent...

-20 CODE 61 MALE X -16 ORFS MALE 90°

Tube OD: 1” Flange size: 1-1/4" Thread: 1-7/16-12

-20 CODE 61 MALE X -20 JIC MALE

Connection type 1: Split flange head Flange size: 1-1/4” Standard: SAE J518 Role: Flange connection Connection type 2: Male JIC Tube OD: 1-1/4" Thread type: 1-5/8-12 UN Standard: SAE J514 – Class 2A thread Role: Line/tube connection Material:...

-20 CODE 61 MALE X -20 JIC MALE 45°

Connection type 1: Split flange head Flange size: 1-1/4" Standard: SAE J518 Role: Flange connection Connection type 2: Male JIC Tube OD: 1-1/4" Thread type: 1-5/8-12 UN Standard: SAE J514 – Class 2A thread Role: Line/tube connection Material:...
