BSP and Metric Adapters

-04 BSPP FEMALE X -04 BSPP MALE BRANCH TEE SWIVEL

BSPP MALE 1: 1/4-19 BSPP MALE 2: 1/4-19 BSPP FEMALE: 1/4-19 L1: 26.5mm L2: 26.5mm Bore: 4.5mm Material: Steel

-04 BSPP FEMALE X -04 BSPP MALE RUN TEE SWIVEL

BSPP Female: 1/4-19 BSPP Male: 1/4-19 (x2) L1: 27mm L2: 27mm Bore: 4mm Material: Steel

-04 BSPP FEMALE X -04 BSPP MALE TEST TEE

Tee thread: 1/4-19 Threads 1 & 2: 1/4-19 Material: Carbon steel

-04 BSPP FEMALE X -04 JIC FEMALE SWIVEL

JIC 1: 7/16-20 UNF JIC 2: 1/4-19 Tube OD: 1/4” Standard: SAE J514 class 2B thread Role: Line connection Working pressure: 5100 psi Burst ratio: 4:1 Material: Trivalent zinc plated steel

-04 BSPP FEMALE X -04 JIC MALE SWIVEL

BSPP: 1/4-19 JIC: 7/16-20 UNF Tube OD: 1/4 Working pressure: 5000 psi Burst ratio: 4:1 Material: Trivalent zinc plated steel

-04 BSPP FEMALE X -04 NPT MALE PORT ADAPTER

Connection type 1: Female BSPP Connection type 2: Male NPTF 30° Thread type 1: 1/4-19 Standard: ISO 1179 Role: Port connection Thread type 2: 1/4-18 NPTF Pipe size: 1/4” Standard: SAE J476

-04 BSPP FEMALE X -06 BSPP MALE TEST TEE

Tee thread: 1/4-19 Threads 1 & 2: 3/8-19 Material: Carbon steel

-04 BSPP FEMALE X -06 JIC MALE SWIVEL

BSPP: 3/8-19 JIC: 7/16-20 UNF Tube OD: 1/4 Working pressure: 4000 psi Burst ratio: 4:1 Material: Trivalent zinc plated steel

-04 BSPP FEMALE X -06 NPT MALE PORT ADAPTER

Connection type 1: Female BSPP Connection type 2: Male NPTF 30° Thread type 1: 3/8-19 Standard: ISO 1179 Role: Port connection Thread type 2: 1/4-28 NPTF Pipe size: 1/4” Standard: SAE J476

-04 BSPP FEMALE X -08 BSPP MALE TEST TEE

Tee thread: 1/4-19 Threads 1 & 2: 1/2-14 Material: Carbon steel

-04 BSPP FEMALE X -12 BSPP MALE TEST TEE

Tee thread: 1/4-19 Threads 1 & 2: 3/4-14 Material: Carbon steel

-04 BSPP FEMALE X -16 BSPP MALE TEST TEE

Tee thread: 1/4-19 Threads 1 & 2: 1-11 Material: Carbon steel
