Standard Adapters

-20 JIC SLEEVE FOR 30MM TUBE

Material: Zinc plated carbon steel

-20 JIC TUBE NUT

Thread: 1-5/8-12 UN Tube OD: 1-1/4” Standard: SAE J514 Role: Line/tube connection Material: Trivalent zinc plated steel Temperature range: -54°C to 260°C (-65°F to 500°F)

-20 JIC TUBE SLEEVE

Tube OD: 1-1/4” Standard: SAE J514 Role: Line/tube connection Material: Trivalent zinc plated steel Temperature range: -54°C to 260°C (-65°F to 500°F)

-20 NPT ALLEN PLUG

Thread: 1-1/4-11.5 Material: Carbon steel

-20 NPT CAP

Thread: 1-1/4-11.5 Material: Carbon steel

-20 NPT FEMALE X -16 JIC MALE

Thread 1 (NPT): 1-1/4-11.5 Thread 2 (JIC): 1-5/16-12 Material: Carbon steel

-20 NPT FEMALE X -16 NPT FEMALE

Thread 1: 1-1/4-11.5 Thread 2: 1-11.5 Material: Carbon steel

-20 NPT FEMALE X -20 JIC FEMALE

Threads 1: 1-1/4-11.5 Thread 2: 1-5/8-12 Material: Carbon steel

-20 NPT FEMALE X -20 JIC MALE

Thread 1 (NPT): 1-1/4-11.5 Thread 2 (JIC): 1-5/8-12 Material: Carbon steel

-20 NPT FEMALE X -20 JIC MALE 90°

Threads 1: 1-1/4-11.5 Thread 2: 1-5/8-12 Material: Carbon steel

-20 NPT FEMALE X -20 NPSM FEMALE

Thread 1: 1-1/4-11.5 Thread 2: 1-1/4-11.5 Material: Carbon steel

-20 NPT FEMALE X -20 NPSM FEMALE 90°

Thread 1: 1-1/4-11.5 Thread 2: 1-1/4-11.5 Material: Carbon steel
