Adapters

-12 BSPT ALLEN PLUG

BSPT: 3/4-14 Length: 12mm Hex size: 12mm Material: Steel

-12 BSPT HEX PLUG

BSPT Male: 3/4-14 Pipe size: 3/4” Standard: ISO 7-1 Role: Pipe connection Material: Trivalent zinc plated steel Working pressure: 5500 psi Burst ratio: 4:1 Temperature range: -54°C to 260°C

-12 BSPT MALE X -08 BSPP MALE

BSPT: 3/4-14 Pipe size: 3/4” Standard: ISO 7-1 Role: Line/pipe connection BSPP: 1/2-14 Standard: ISO 8434-6 ISO 1179 Role: Line/port connection Working pressure: 1700 psi Burst ratio:

-12 BSPT MALE X -12 BSPP MALE

BSPT: 3/4-14 Pipe size: 3/4” Standard: ISO 7-1 Role: Line/pipe connection BSPP: 3/4-14 Standard: ISO 8434-6 ISO 1179 Role: Line/port connection Working pressure: 2900 psi Burst ratio:

-12 BSPT MALE X -12 JIC MALE

BSPT: 3/4-14 Pipe size: 3/4” Standard: ISO 7-1 Role: Line/pipe connection JIC: 1-1/16-12 UN Tube size: 3/4" Standard: SAE J514 class 2A thread Role: Line/tube connection Working pressure:

-12 BSPT MALE X 20S DIN MALE 90°

BSPT: 3/4-14 DIN: M30 X 2 Material: Steel

-12 BSPT MALE X 22L DIN MALE 90°

BSPT: 3/4-14 DIN: M30 X 2 Material: Steel

-12 CAT STYLE FLANGE PLUG

Flange size: 3/4” A: 1.625 in (41.3mm) B: 1.250 in (31.7mm) C: 0.560 in (14.2mm) Material: Carbon steel

-12 CAT STYLE SPLIT FLANGE KIT

Includes: (2) split flange halves, (4) hex head bolts and flat washers. Material: Carbon steel Flange size: 3/4” A: 2.950 in (74.9mm) B: 2.00 in (50.8mm) C: 0.446 in (11.3mm) D: 1.210 in (30.7mm) E:...

-12 CODE 61 CLAMP KIT

Kit includes: 2 – Flange halves 4 – Grade 8 hex head cap screws 4 – Hardened flat washers 1 – Nitrile O-ring Thread type: Code 61 flange Thread: 3/4”

-12 CODE 61 FLANGE PLUG

Connection type: Flange plug Flange size: 3/4” Standard: SAE J518 Role: Flange connection Material: Trivalent zinc plated carbon steel Working pressure: 5000 psi Burst ratio: 4:1 Temperature range:...

-12 CODE 61 MALE X -08 JIC MALE

Connection type 1: Split flange head Flange size: 3/4” Standard: SAE J518 Role: Flange connection Connection type 2: Male JIC Tube OD: 1/2" Thread type: 3/4-16 UNF Standard: SAE J514 – Class 2A thread
