BSP Straights

-02 BSP BULKHEAD MALE X -02 BSP MALE WITH LOCKNUT

Thread 1 & 2: 1/8-28 Hex: 14mm Length: 45mm Bore: 3mm Material: Carbon steel

-02 BSP MALE X -04 JIC MALE

Straight Adapter with BSP Male -02 and JIC Male -04 Threads CH hex size: 14mm JIC: 7/16-20 BSPP: 1/8-28 Material: Steel

-02 BSP MALE X -06 JIC MALE

Straight Adapter with BSP Male -02 and JIC Male -06 Threads CH hex size: 17mm JIC: 9/16-18 BSPP: 1/8-28 Material: Steel

-02 BSP/BSPP ELASTOMER SEAL X -04 JIC MALE

BSPP: 1/8-28 JIC: 7/16-20 Material: Carbon steel body, Buna-N (nitrile) seal

-02 BSPP ELASTOMER MALE X 06L DIN FEMALE SWIVEL

BSPP: 1/8-28 DIN: M12 x 1.5 Material: Carbon steel body, Buna-N (nitrile) seal Pressure size/tube rating: Light duty

-02 BSPP ELASTOMER MALE X 06L DIN MALE

BSPP: 1/8-28 DIN: M12 x 1.5 Material: Carbon steel body, Buna-N (nitrile) seal Pressure size/tube rating: Light duty

-02 BSPP ELASTOMER MALE X 08L DIN MALE

BSPP: 1/8-28 DIN: M14 x 1.5 Material: Carbon steel body, Buna-N (nitrile) seal Pressure size/tube rating: Light duty

-02 BSPP FEMALE SWIVEL X -02 NPT MALE

BSPP: 1/8-28 Standard: ISO 8434-6 Role: Line connection NPT: 1/8-27 NPTF Pipe size: 1/8” Standard: SAE J476 Role: Line/pipe connection Working pressure: 5100 psi Burst ratio: 4:1 Material: Trivalent zinc plated steel

-02 BSPP FEMALE X -02 BSPP FEMALE HEX COUPLING

Connection type 1: Female BSPP Connection type 2: Female BSPP Thread type 1: 1/8-28 Thread type 2: 1/8-28 Standard: ISO 1179 Role: Port connection Working pressure: 6000 psi Burst ratio: 4:1 Material: Trivalent zinc plated steel

-02 BSPP FEMALE X -02 NPT MALE PORT ADAPTER

Connection type 1: Female BSPP Connection type 2: Male NPTF 30° Thread type 1: 1/8-28 Standard: ISO 1179 Role: Port connection Thread type 2: 1/8-27 NPTF Pipe size: 1/8” Standard: SAE J476 Role: Line/pipe connection Working pressure: 6000...

-02 BSPP FEMALE X -04 JIC MALE SWIVEL

BSPP: 1/8-28 JIC: 7/16-20 UNF Tube OD: 1/4 Working pressure: 5000 psi Burst ratio: 4:1 Material: Trivalent zinc plated steel

-02 BSPP FEMALE X -04 NPT MALE PORT ADAPTER

Connection type 1: Female BSPP Connection type 2: Male NPTF 30° Thread type 1: 1/4-19 Standard: ISO 1179 Role: Port connection Thread type 2: 1/8-27 NPTF Pipe size: 1/8” Standard: SAE J476 Role: Line/pipe connection Working pressure: 6000...
