BSP Straights

-04 BSPP FEMALE X -06 NPT MALE PORT ADAPTER

Connection type 1: Female BSPP Connection type 2: Male NPTF 30° Thread type 1: 3/8-19 Standard: ISO 1179 Role: Port connection Thread type 2: 1/4-28 NPTF Pipe size: 1/4” Standard: SAE J476

-04 BSPP FEMALE X 06S DIN MALE

CH hex size: 19mm DIN: 14 x 1.5 Size/tube rating: Heavy duty BSPP: 1/4-19 L1: 33mm L2: 17mm L3: 9mm Minimum bore: 4mm Tube size: S06 Material: Zinc plated steel

-04 BSPP FEMALE X 08L DIN MALE

CH hex size: 16mm DIN: 14 x 1.5 Size/tube rating: Light duty BSPP: 1/4-19 L1: 31mm L2: 17mm L3: 7mm Minimum bore: 6mm Tube size: L08 Material: Zinc plated steel

-04 BSPP FEMALE X 08L DIN MALE GAUGE ADAPTER

Thread 1: M14x1.5 Thread 2: 1/4-19 Material: Carbon steel

-04 BSPP FEMALE X 08S DIN MALE

CH hex size: 19mm DIN: 16 x 1.5 Size/tube rating: Heavy duty BSPP: 1/4-19 L1: 33mm L2: 17mm L3: 9mm Minimum bore: 5mm Tube size: S08 Material: Zinc plated steel

-04 BSPP FEMALE X 10L DIN MALE

CH hex size: 19mm DIN: 16 x 1.5 Size/tube rating: Light duty BSPP: 1/4-19 L1: 32mm L2: 17mm L3: 8mm Minimum bore: 8mm Tube size: L10 Material: Zinc plated steel

-04 BSPP FEMALE X 10L DIN MALE GAUGE ADAPTER

Thread 1: M16x1.5 Thread 2: 1/4-19 Material: Carbon steel

-04 BSPP FEMALE X 12L DIN MALE GAUGE ADAPTER

Thread 1: M18x1.5 Thread 2: 1/4-19 Material: Carbon steel

-04 BSPP MALE ORR X -04 NPT FEMALE

BSPP: 1/4-19 NPT: 1/4-18 Material: Steel body, Buna-N (nitrile) seal

-04 BSPP MALE X -02 BSPP FEMALE SWIVEL

CH Hex size: 19mm CH2 Hex size: 14mm BSPP Male: 1/4-19 BSPP Female: 1/8-28 L: 32mm L1: 11mm L2: 14.5mm Bore: 4.5mm Material: Steel

-04 BSPP MALE X -02 BSPP MALE

CH Hex size: 19mm BSPP 1: 1/4-19 BSPP 2: 1/8-28 L: 28.5mm L1: 11mm L2: 9.5mm Bore: 4.5mm Material: Steel

-04 BSPP MALE X -02 NPT FEMALE

BSPP: 1/8-28 Standard: ISO 8434-6, ISO 1179 Role: Line/port connection NPT: 1/4-18 NPTF Pipe size: 1/4” Standard: SAE J476 Role: Pipe connection Working pressure: 5100 psi Burst ratio:
