BSP Straights

-02 BSPT MALE X -02 BSPP MALE

BSPT: 1/8-28 Pipe size: 1/8” Standard: ISO 7-1 Role: Line/pipe connection BSPP: 1/8-28 Standard: ISO 8434-6 ISO 1179 Role: Line/port connection Working pressure: 5100 psi Burst ratio: 4:1 Material: Trivalent zinc plated steel Temperature range:...

-02 BSPT MALE X -02 BSPT MALE

BSPT 1: 1/8-28 Pipe size: 1/8” Standard: ISO 7-1 Role: Line/pipe connection BSPT 2: 1/8-28 Pipe size: 1/8" Standard: ISO 7-1 Role: Line/pipe connection Working pressure: 6000 psi Burst ratio: 4:1 Temperature range:  -54°C to 260°C...

-02 BSPT MALE X -02 NPT FEMALE

BSPT: 1/8-28 NPT: 1/8-27 L1: 10mm L2: 25mm Minimum bore: 4.5mm Material: Steel

-02 BSPT MALE X -04 BSPP MALE

BSPT: 1/8-28 Pipe size: 1/8” Standard: ISO 7-1 Role: Line/pipe connection BSPP: 1/4-19 Standard: ISO 8434-6 ISO 1179 Role: Line/port connection Working pressure: 5100 psi Burst ratio: 4:1 Material: Trivalent zinc plated steel Temperature range:...

-02 BSPT MALE X -04 JIC MALE

BSPT: 1/8-28 Pipe size: 1/8” Standard: ISO 7-1 Role: Line/pipe connection JIC: 7/16-20 UNF Tube size: 1/4" Standard: SAE J514 class 2A thread Role: Line/tube connection Working pressure: 4500 psi Burst ratio: 4:1 Temperature range:  -54°C...

-02 BSPT MALE X 04LL DIN MALE

BSPT: 1/8-28 DIN: M8 X 1 L1: 8mm L2: 8mm Minimum bore: 3mm Material: Steel

-02 BSPT MALE X 06LL DIN MALE

BSPT: 1/8-28 DIN: M10 X 1 L1: 8mm L2: 8mm Minimum bore: 4.5mm Material: Steel

-02 BSPT MALE X 08L DIN MALE

BSPT: 1/8-28 DIN: M14 X 1.5 L1: 10.5mm L2: 10.5mm Minimum bore: 4.5mm Material: Steel

-04 BSP BULKHEAD MALE X -04 BSP MALE WITH LOCKNUT

Thread 1 & 2: 1/4-19 Hex: 19mm Length: 46mm Bore: 4.5mm Material: Carbon steel

-04 BSP MALE X -04 ORB MALE

BSP: 1/4-19 ORB: 7/16-20 Material: Carbon steel body, Buna-N (nitrile) seal

-04 BSP MALE X -06 ORB MALE

BSP: 1/4-19 ORB: 9/16-18 Material: Carbon steel body, Buna-N (nitrile) seal

-04 BSP/BSPP ELASTOMER SEAL X -04 JIC MALE

BSPP: 1/4-19 JIC: 7/16-20 Material: Carbon steel body, Buna-N (nitrile) seal
