BSP Straights

-06 BSPP O-RING MALE X -04 ORFS MALE

BSPP: 3/8-19 ORFS: 9/16-18 Material: Steel Seal material: Buna-N (nitrile)

-06 BSPP O-RING MALE X -06 BSP MALE

Hex size: 24mm BSPP: 3/8-19 BSP: 3/8-19 L1: 12mm L2: 13.5mm Minimum bore: 9mm Material: Steel

-06 BSPP O-RING MALE X -06 ORFS MALE

BSPP: 3/8-19 ORFS: 11/16-16 Material: Steel Seal material: Buna-N (nitrile)

-06 BSPP O-RING MALE X -08 ORFS MALE

BSPP: 3/8-19 ORFS: 13/16-16 Material: Steel Seal material: Buna-N (nitrile)

-06 BSPP SWIVEL FEMALE X -08 JIC MALE

BSPP: 1/2-14 JIC: 9/16-18 UNF Tube OD: 3/8 Working pressure: 4000 psi Burst ratio: 4:1 Material: Trivalent zinc plated steel

-06 BSPT MALE X -04 BSPP MALE

BSPT: 3/8-19 Pipe size: 3/8” Standard: ISO 7-1 Role: Line/pipe connection BSPP: 1/4-19 Standard: ISO 8434-6 ISO 1179 Role: Line/port connection Working pressure: 4100 psi Burst ratio:

-06 BSPT MALE X -06 BSPP MALE

BSPT: 3/8-19 Pipe size: 3/8” Standard: ISO 7-1 Role: Line/pipe connection BSPP: 3/8-19 Standard: ISO 8434-6 ISO 1179 Role: Line/port connection Working pressure: 5100 psi Burst ratio:

-06 BSPT MALE X -06 BSPT MALE

BSPT 1: 3/8-19 Pipe size: 3/8” Standard: ISO 7-1 Role: Line/pipe connection BSPT 2: 3/8-19 Pipe size: 3/8” Standard: ISO 7-1 Role: Line/pipe connection Working pressure: 6000 p

-06 BSPT MALE X -06 JIC MALE

BSPT: 3/8-19 Pipe size: 3/8” Standard: ISO 7-1 Role: Line/pipe connection JIC: 9/16-18 UNF Tube size: 3/8" Standard: SAE J514 class 2A thread Role: Line/tube connection Working pressure:

-06 BSPT MALE X -06 NPT FEMALE

BSPT: 3/8-19 NPT: 3/8-18 L1: 15.5mm L2: 37mm Minimum bore: 9mm Material: Steel

-06 BSPT MALE X -08 JIC MALE

BSPT: 3/8-19 Pipe size: 3/8” Standard: ISO 7-1 Role: Line/pipe connection JIC: 3/4-16 UNF Tube size: 1/2" Standard: SAE J514 class 2A thread Role: Line/tube connection Working pressure:

-08 BSP BULKHEAD MALE X -08 BSP MALE WITH LOCKNUT

Thread 1 & 2: 1/2-14 Hex: 27mm Length: 65.5mm Bore: 11.5mm Material: Carbon steel
