BSP Straights

-06 BSPP MALE X -08 BSPP FEMALE SWIVEL

CH Hex size: 22mm CH2 Hex size: 27mm BSPP Male: 3/8-19 BSPP Female: 1/2-14 L: 41mm L1: 12mm L2: 23mm Bore: 8mm Material: Steel

-06 BSPP MALE X -08 JIC FEMALE SWIVEL

BSPP: 1/2-14 JIC: 9/16-18 UNF Tube OD: 3/8 Working pressure: 2900 psi Burst ratio: 4:1 Material: Trivalent zinc plated steel

-06 BSPP MALE X -08 NPT FEMALE

BSPP: 1/2-14 Standard: ISO 8434-6, ISO 1179 Role: Line/port connection NPT: 3/8-18 NPTF Pipe size: 3/8” Standard: SAE J476 Role: Pipe connection Working pressure: 2900 psi Burst ratio:

-06 BSPP MALE X -08 NPT MALE

BSPP: 1/2-14 Standard: ISO 8434-6, ISO 1179 Role: Line/port connection NPT: 3/8-18 NPTF Pipe size: 3/8” Standard: SAE J476 Role: Line/pipe connection Working pressure: 2900 psi Burst ratio: <

-06 BSPP MALE X -10 JIC FEMALE SWIVEL

BSPP: 5/8-14 JIC: 9/16-18 UNF Tube OD: 3/8 Working pressure: 2900 psi Burst ratio: 4:1 Material: Trivalent zinc plated steel

-06 BSPP MALE X -10 JIC MALE

Straight Adapter with BSP Male -06 and JIC Male -10 Threads CH hex size: 25mm JIC: 7/8-14 BSPP: 3/8-19 Material: Steel

-06 BSPP MALE X -12 NPT MALE

BSPP: 3/4-14 Standard: ISO 8434-6, ISO 1179 Role: Line/port connection NPT: 3/8-18 NPTF Pipe size: 3/8” Standard: SAE J476 Role: Line/pipe connection Working pressure: 2900 psi Burst ratio: <

-06 BSPP O-RING MALE X -04 JIC MALE

CH hex size: 24mm JIC: 7/16-20 BSPP: 3/8-19 Material: Steel

-06 BSPP O-RING MALE X -06 JIC MALE

CH hex size: 24mm JIC: 9/16-18 BSPP: 3/8-19 Material: Steel

-06 BSPP O-RING MALE X -08 JIC MALE

CH hex size: 24mm JIC: 3/4-16 BSPP: 3/8-19 Material: Steel

-06 BSPP O-RING MALE X -10 JIC MALE

JIC: 7/8-14 BSPP: 3/8-19 Material: Steel

-06 BSPP O-RING MALE X -12 JIC MALE

JIC: 1-1/16-12 BSPP: 3/8-19 Material: Steel
