BSP Straights

-06 BSPP MALE X -02 BSPP MALE

CH Hex size: 14mm BSPP 1: 3/8-19 BSPP 2: 1/8-28 L: 33mm L1: 15mm L2: 9.5mm Bore: 4.5mm Material: Steel

-06 BSPP MALE X -04 BSPP FEMALE SWIVEL

CH Hex size: 22mm CH2 Hex size: 19mm BSPP Male: 3/8-19 BSPP Female: 1/4-19 L: 37mm L1: 13mm L2: 17.5mm Bore: 4.5mm Material: Steel

-06 BSPP MALE X -04 BSPP MALE

CH Hex size: 22mm BSPP 1: 3/8-19 BSPP 2: 1/4-19 L: 31mm L1: 12mm L2: 11mm Bore: 6.5mm Material: Steel

-06 BSPP MALE X -04 JIC FEMALE SWIVEL

BSPP: 1/4-19 JIC: 9/16-18 UNF Tube OD: 3/8 Working pressure: 5100 psi Burst ratio: 4:1 Material: Trivalent zinc plated steel

-06 BSPP MALE X -04 JIC MALE

Straight Adapter with BSP Male -06 and JIC Male -04 Threads CH hex size: 19mm JIC: 9/16-18 BSPP: 1/4-19 Material: Steel

-06 BSPP MALE X -04 NPT FEMALE

BSPP: 1/4-19 Standard: ISO 8434-6, ISO 1179 Role: Line/port connection NPT: 3/8-18 NPTF Pipe size: 3/8” Standard: SAE J476 Role: Pipe connection Working pressure: 5100 psi Burst ratio: 4:1 Material: Trivalent zinc plated steel

-06 BSPP MALE X -04 NPT MALE

BSPP: 1/4-19 Standard: ISO 8434-6, ISO 1179 Role: Line/port connection NPT: 3/8-18 NPTF Pipe size: 3/8” Standard: SAE J476 Role: Line/pipe connection Working pressure: 5100 psi Burst ratio: 4:1 Material: Trivalent zinc plated steel

-06 BSPP MALE X -04 ORFS MALE

BSPP:  3/8-19 ORFS:  9/16-18 Length: 31.5mm Minimum bore: 4mm Material: Steel (body) Nitrile butadiene rubber (o-ring)

-06 BSPP MALE X -06 BSPP FEMALE SWIVEL

CH Hex size: 22mm CH2 Hex size: 22mm BSPP Male: 3/8-19 BSPP Female: 3/8-19 L: 39.5mm L1: 13mm L2: 21.5mm Bore: 8mm Material: Steel

-06 BSPP MALE X -06 BSPP MALE

CH Hex size: 14mm BSPP 1: 3/8-19 BSPP 2: 3/8-19 L: 32mm L1: 12mm L2: 12mm Bore: 8.5mm Material: Steel

-06 BSPP MALE X -06 JIC FEMALE SWIVEL

BSPP: 3/8-19 JIC: 9/16-18 UNF Tube OD: 3/8 Working pressure: 5100 psi Burst ratio: 4:1 Material: Trivalent zinc plated steel

-06 BSPP MALE X -06 NPT FEMALE

BSPP: 3/8-19 Standard: ISO 8434-6, ISO 1179 Role: Line/port connection NPT: 3/8-18 NPTF Pipe size: 3/8” Standard: SAE J476 Role: Pipe connection Working pressure: 5100 psi Burst ratio: 4:1 Material: Trivalent zinc plated steel
