BSP Straights

-12 BSPP O-RING MALE X -20 JIC MALE

JIC: 1-5/8-12 BSPP: 3/4-14 Material: Steel

-12 BSPP O-RING MALE X -08 ORFS MALE

BSPP: 3/4-14 ORFS: 13/16-16 Material: Steel Seal material: Buna-N (nitrile)

-12 BSPP O-RING MALE X -10 ORFS MALE

BSPP: 3/4-14 ORFS: 1-14 Material: Steel Seal material: Buna-N (nitrile)

-12 BSPP O-RING MALE X -12 BSP MALE

Hex size: 36mm BSPP: 3/4-14 BSP: 3/4-14 L1: 15mm L2: 18.5mm Minimum bore: 15.5mm Material: Steel

-12 BSPP O-RING MALE X -12 ORFS MALE

BSPP: 3/4-12 ORFS: 1-3/16-12 Material: Steel Seal material: Buna-N (nitrile)

-12 BSPP O-RING MALE X -16 ORFS MALE

BSPP: 3/4-14 ORFS: 1-7/16-12 Material: Steel Seal material: Buna-N (nitrile)

-12 BSPT MALE X -08 BSPP MALE

BSPT: 3/4-14 Pipe size: 3/4” Standard: ISO 7-1 Role: Line/pipe connection BSPP: 1/2-14 Standard: ISO 8434-6 ISO 1179 Role: Line/port connection Working pressure: 1700 psi Burst ratio: 4:1 Material: Trivalent zinc plated steel Temperature range:...

-12 BSPT MALE X -12 BSPP MALE

BSPT: 3/4-14 Pipe size: 3/4” Standard: ISO 7-1 Role: Line/pipe connection BSPP: 3/4-14 Standard: ISO 8434-6 ISO 1179 Role: Line/port connection Working pressure: 2900 psi Burst ratio: 4:1 Material: Trivalent zinc plated steel Temperature range:...

-12 BSPT MALE X -12 JIC MALE

BSPT: 3/4-14 Pipe size: 3/4” Standard: ISO 7-1 Role: Line/pipe connection JIC: 1-1/16-12 UN Tube size: 3/4" Standard: SAE J514 class 2A thread Role: Line/tube connection Working pressure: 2300 psi Burst ratio: 4:1 Temperature range:  -54°C...

-16 BSP BULKHEAD MALE X -16 BSP MALE WITH LOCKNUT

Thread 1 & 2: 1-11 Hex: 40.5mm Length: 75mm Bore: 22mm Material: Carbon steel

-16 BSP MALE X -12 ORB MALE

BSP: 1-11 ORB: 1-1/16-14 Material: Carbon steel body, Buna-N (nitrile) seal

-16 BSP MALE X -16 ORB MALE

BSP: 1-11 ORB: 1-5/16-14 Material: Carbon steel body, Buna-N (nitrile) seal
