BSP Straights

-12 BSPP FEMALE SWIVEL X -16 NPT MALE

BSPP: 1-11 Standard: ISO 8434-6 Role: Line connection NPT: 3/4-14 NPTF Pipe size: 3/4” Standard: SAE J476 Role: Line/pipe connection Working pressure: 1700 psi Burst ratio: 4:1 Material: Trivalent zinc plated steel

-12 BSPP FEMALE X -08 BSPP FEMALE HEX COUPLING

Connection type 1: Female BSPP Connection type 2: Female BSPP Thread type 1: 3/4-14 Thread type 2: 1/2-14 Standard: ISO 1179 Role: Port connection Working pressure: 3000 psi Burst ratio: 4:1 Material: Trivalent zinc plated steel

-12 BSPP FEMALE X -08 NPT MALE PORT ADAPTER

Connection type 1: Female BSPP Connection type 2: Male NPTF 30° Thread type 1: 1/2-14 Standard: ISO 1179 Role: Port connection Thread type 2: 3/4-14 NPTF Pipe size: 3/4” Standard: SAE J476 Role: Line/pipe connection Working pressure: 4000...

-12 BSPP FEMALE X -12 BSPP FEMALE HEX COUPLING

Connection type 1: Female BSPP Connection type 2: Female BSPP Thread type 1: 3/4-14 Thread type 2: 3/4-14 Standard: ISO 1179 Role: Port connection Working pressure: 3000 psi Burst ratio: 4:1 Material: Trivalent zinc plated steel

-12 BSPP FEMALE X -12 BSPP FEMALE SWIVEL

BSPP 1 & 2: 3/4-14 Length: 57mm Minimum bore: 15.5mm Material: Steel

-12 BSPP FEMALE X -12 JIC FEMALE SWIVEL

JIC 1: 1-1/16-12 UNF JIC 2: 3/4-14 Tube OD: 3/4” Standard: SAE J514 class 2B thread Role: Line connection Working pressure: 2900 psi Burst ratio: 4:1 Material: Trivalent zinc plated steel

-12 BSPP FEMALE X -12 NPT MALE PORT ADAPTER

Connection type 1: Female BSPP Connection type 2: Male NPTF 30° Thread type 1: 3/4-14 Standard: ISO 1179 Role: Port connection Thread type 2: 3/4-14 NPTF Pipe size: 3/4” Standard: SAE J476 Role: Line/pipe connection Working pressure: 4000...

-12 BSPP FEMALE X -16 NPT MALE PORT ADAPTER

Connection type 1: Female BSPP Connection type 2: Male NPTF 30° Thread type 1: 1-11 Standard: ISO 1179 Role: Port connection Thread type 2: 3/4-14 NPTF Pipe size: 3/4” Standard: SAE J476 Role: Line/pipe connection Working pressure: 4500...

-12 BSPP FEMALE X 20S DIN MALE

CH hex size: 36mm DIN: 30 x 2.0 Size/tube rating: Heavy duty BSPP: 3/4-14 L1: 45mm L2: 22mm L3: 12.5mm Minimum bore: 16mm Tube size: S20 Material: Zinc plated steel

-12 BSPP FEMALE X 22L DIN MALE

CH hex size: 36mm DIN: 30 x 2.0 Size/tube rating: Heavy duty BSPP: 3/4-14 L1: 43mm L2: 14mm L3: 29mm Minimum bore: 19mm Tube size: L22 Material: Zinc plated steel

-12 BSPP MALE X -06 BSPP MALE

CH Hex size: 32mm BSPP 1: 3/4-14 BSPP 2: 3/8-19 L: 40mm L1: 16.5mm L2: 12mm Bore: 8mm Material: Steel

-12 BSPP MALE X -06 NPT MALE

BSPP: 3/8-19 Standard: ISO 8434-6, ISO 1179 Role: Line/port connection NPT: 3/4-14 NPTF Pipe size: 3/4” Standard: SAE J476 Role: Line/pipe connection Working pressure: 5100 psi Burst ratio: 4:1 Material: Trivalent zinc plated steel
