BSP Straights

-12 BSPP ELASTOMER MALE X 18L DIN MALE

BSPP: 3/4-14 DIN: M26 x 1.5 Material: Carbon steel body, Buna-N (nitrile) seal Pressure size/tube rating: Light duty

-12 BSPP ELASTOMER MALE X 20S DIN FEMALE SWIVEL

BSPP: 3/4-14 DIN: M22 x 1.5 Material: Carbon steel body, Buna-N (nitrile) seal Pressure size/tube rating: Heavy duty

-12 BSPP ELASTOMER MALE X 20S DIN MALE

BSPP: 3/4-14 DIN: M30 x 2 Material: Carbon steel body, Buna-N (nitrile) seal Pressure size/tube rating: Heavy duty

-12 BSPP ELASTOMER MALE X 22L DIN FEMALE SWIVEL

BSPP: 3/4-14 DIN: M30 x 2 Material: Carbon steel body, Buna-N (nitrile) seal Pressure size/tube rating: Light duty

-12 BSPP ELASTOMER MALE X 22L DIN MALE

BSPP: 3/4-14 DIN: M30 x 2 Material: Carbon steel body, Buna-N (nitrile) seal Pressure size/tube rating: Light duty

-12 BSPP ELASTOMER MALE X 25S DIN MALE

BSPP: 3/4-14 DIN: M36 x 2 Material: Carbon steel body, Buna-N (nitrile) seal Pressure size/tube rating: Heavy duty

-12 BSPP FEMALE SWIVEL X -08 JIC MALE

BSPP: 1/2-14 JIC: 1-1/16-12 UN Tube OD: 3/4 Working pressure: 4000 psi Burst ratio: 4:1 Material: Trivalent zinc plated steel

-12 BSPP FEMALE SWIVEL X -12 JIC MALE

BSPP: 3/4-14 JIC: 1-1/16-12 UN Tube OD: 3/4 Working pressure: 4000 psi Burst ratio: 4:1 Material: Trivalent zinc plated steel

-12 BSPP FEMALE SWIVEL X -12 NPT MALE

BSPP: 3/4-14 Standard: ISO 8434-6 Role: Line connection NPT: 3/4-14 NPTF Pipe size: 3/4” Standard: SAE J476 Role: Line/pipe connection Working pressure: 2900 psi Burst ratio: 4:1

-12 BSPP FEMALE SWIVEL X -16 NPT MALE

BSPP: 1-11 Standard: ISO 8434-6 Role: Line connection NPT: 3/4-14 NPTF Pipe size: 3/4” Standard: SAE J476 Role: Line/pipe connection Working pressure: 1700 psi Burst ratio: 4:1 <

-12 BSPP FEMALE X -08 BSPP FEMALE HEX COUPLING

Connection type 1: Female BSPP Connection type 2: Female BSPP Thread type 1: 3/4-14 Thread type 2: 1/2-14 Standard: ISO 1179 Role: Port connection Working pressure: 3000 psi Burst ratio: 4:1 Materi

-12 BSPP FEMALE X -08 NPT MALE PORT ADAPTER

Connection type 1: Female BSPP Connection type 2: Male NPTF 30° Thread type 1: 1/2-14 Standard: ISO 1179 Role: Port connection Thread type 2: 3/4-14 NPTF Pipe size: 3/4” Standard: SAE J476
