BSP Straights

-08 BSPT MALE X -10 BSPP MALE

BSPT: 1/2-14 Pipe size: 1/2” Standard: ISO 7-1 Role: Line/pipe connection BSPP: 5/8-14 Standard: ISO 8434-6 ISO 1179 Role: Line/port connection Working pressure: 2900 psi Burst ratio: 4:1 Material: Trivalent zinc plated steel Temperature range:...

-10 BSP BULKHEAD MALE X -10 BSP MALE WITH LOCKNUT

Thread 1 & 2: 5/8-14 Hex: 30mm Length: 63mm Bore: 14mm Material: Carbon steel

-10 BSP/BSPP ELASTOMER SEAL X -08 JIC MALE

BSPP: 5/8-14 JIC: 3/4-16 Material: Carbon steel body, Buna-N (nitrile) seal

-10 BSP/BSPP ELASTOMER SEAL X -10 JIC MALE

BSPP: 5/8-14 JIC: 7/8-14 Material: Carbon steel body, Buna-N (nitrile) seal

-10 BSP/BSPP ELASTOMER SEAL X -12 JIC MALE

BSPP: 5/8-14 JIC: 1-1/16-12 Material: Carbon steel body, Buna-N (nitrile) seal

-10 BSPP FEMALE SWIVEL X -08 JIC MALE

BSPP: 1/2-14 JIC: 7/8-14 UNF Tube OD: 5/8 Working pressure: 4000 psi Burst ratio: 4:1 Material: Trivalent zinc plated steel

-10 BSPP FEMALE SWIVEL X -10 JIC MALE

BSPP: 5/8-14 JIC: 7/18-14 UNF Tube OD: 5/8 Working pressure: 4000 psi Burst ratio: 4:1 Material: Trivalent zinc plated steel

-10 BSPP FEMALE X -08 BSPP FEMALE HEX COUPLING

Connection type 1: Female BSPP Connection type 2: Female BSPP Thread type 1: 5/8-14 Thread type 2: 1/2-14 Standard: ISO 1179 Role: Port connection Working pressure: 3000 psi Burst ratio: 4:1 Material: Trivalent zinc plated steel

-10 BSPP FEMALE X -10 BSPP FEMALE HEX COUPLING

Connection type 1: Female BSPP Connection type 2: Female BSPP Thread type 1: 5/8-14 Thread type 2: 5/8-14 Standard: ISO 1179 Role: Port connection Working pressure: 3000 psi Burst ratio: 4:1 Material: Trivalent zinc plated steel

-10 BSPP FEMALE X -10 BSPP FEMALE SWIVEL

BSPP 1 & 2: 5/8-14 Length: 47mm Minimum bore: 13mm Material: Steel

-10 BSPP FEMALE X -10 JIC FEMALE SWIVEL

JIC 1: 7/8-14 UNF JIC 2: 5/8-14 Tube OD: 5/8” Standard: SAE J514 class 2B thread Role: Line connection Working pressure: 2900 psi Burst ratio: 4:1 Material: Trivalent zinc plated steel

-10 BSPP MALE X -08 BSPP FEMALE SWIVEL

CH Hex size: 26mm CH2 Hex size: 26mm BSPP Male: 5/8-14 BSPP Female: 1/2-14 L: 45mm L1: 16.5mm L2: 22.5mm Bore: 10.5mm Material: Steel
