BSP Straights

-10 BSPP MALE X -08 BSPP MALE

CH Hex size: 30mm BSPP 1: 5/8-14 BSPP 2: 1/2-14 L: 39.5mm L1: 17mm L2: 14mm Bore: 12mm Material: Steel

-10 BSPP MALE X -08 NPT MALE

BSPP: 5/8-14 Standard: ISO 8434-6, ISO 1179 Role: Line/port connection NPT: 1/2-14 NPTF Pipe size: 1/2” Standard: SAE J476 Role: Line/pipe connection Working pressure: 1700 psi Burst ratio: 4:1 Material: Trivalent zinc plated steel

-10 BSPP MALE X -10 BSPP FEMALE SWIVEL

CH Hex size: 30mm CH2 Hex size: 30mm BSPP Male: 5/8-14 BSPP Female: 5/8-14 L: 54mm L1: 18mm L2: 28mm Bore: 14.5 Material: Steel

-10 BSPP MALE X -10 BSPP MALE

CH Hex size: 30mm BSPP 1: 5/8-14 BSPP 2: 5/8-14 L: 41.5mm L1: 17mm L2: 17mm Bore: 14mm Material: Steel

-10 BSPP MALE X -10 JIC FEMALE SWIVEL

BSPP: 5/8-14 JIC: 7/8-14 UNF Tube OD: 5/8 Working pressure: 2900 psi Burst ratio: 4:1 Material: Trivalent zinc plated steel

-10 BSPP MALE X -10 JIC MALE

Straight Adapter with BSP Male -10 and JIC Male -10 Threads CH hex size: 30mm JIC: 7/8-14 BSPP: 5/8-14 Material: Steel

-10 BSPP MALE X -10 ORFS MALE

BSPP: 5/8-14 ORFS: 1-14 Length: 43mm Minimum bore: 12.5mm Material: Steel (body) Nitrile butadiene rubber (o-ring)

-10 BSPP MALE X -12 BSPP FEMALE SWIVEL

CH Hex size: 30mm CH2 Hex size: 32mm BSPP Male: 5/8-14 BSPP Female: 3/4-14 L: 50mm L1: 17mm L2: 28mm Bore: 14.5mm Material: Steel

-10 BSPP MALE X -12 JIC MALE

Straight Adapter with BSP Male -10 and JIC Male -12 Threads CH hex size: 28mm JIC: 1-1/16-12 BSPP: 5/8-14 Material: Steel

-10 BSPP MALE X -12 NPT MALE

BSPP: 5/8-14 Standard: ISO 8434-6, ISO 1179 Role: Line/port connection NPT: 3/4-14 NPTF Pipe size: 3/4” Standard: SAE J476 Role: Line/pipe connection Working pressure: 1700 psi Burst ratio: 4:1 Material: Trivalent zinc plated steel

-10 BSPP O-RING MALE X -08 JIC MALE

JIC: 3/4-16 BSPP: 5/8-14 Material: Steel

-12 BSP BULKHEAD MALE X -12 BSP MALE WITH LOCKNUT

Thread 1 & 2: 3/4-14 Hex: 31.5mm Length: 65.5mm Bore: 16.5mm Material: Carbon steel
