BSP Straights

-04 BSPP MALE X -06 NPT MALE

BSPP: 3/8-19 Standard: ISO 8434-6, ISO 1179 Role: Line/port connection NPT: 1/4-18 NPTF Pipe size: 1/4” Standard: SAE J476 Role: Line/pipe connection Working pressure: 5100 psi Burst ratio: 4:1 Material: Trivalent zinc plated steel

-04 BSPP MALE X -08 BSPP FEMALE SWIVEL

CH Hex size: 22mm CH2 Hex size: 27mm BSPP Male: 1/4-19 BSPP Female: 1/2-14 L: 41mm L1: 11.5mm L2: 24.5mm Bore: 4.5mm Material: Steel

-04 BSPP MALE X -08 JIC FEMALE SWIVEL

BSPP: 1/2-14 JIC: 7/16-20 UNF Tube OD: 1/4 Working pressure: 2900 psi Burst ratio: 4:1 Material: Trivalent zinc plated steel

-04 BSPP MALE X -08 JIC MALE

Straight Adapter with BSP Male -04 and JIC Male -08 Threads CH hex size: 21mm JIC: 3/4-16 BSPP: 1/4-19 Material: Steel

-04 BSPP MALE X -08 NPT MALE

BSPP: 1/2-14 Standard: ISO 8434-6, ISO 1179 Role: Line/port connection NPT: 1/4-18 NPTF Pipe size: 1/4” Standard: SAE J476 Role: Line/pipe connection Working pressure: 2900 psi Burst ratio: 4:1 Material: Trivalent zinc plated steel

-04 BSPP O-RING MALE X -04 JIC MALE

CH hex size: 19mm JIC: 7/16-20 BSPP: 1/4-19 Material: Steel

-04 BSPP O-RING MALE X -04 JIC MALE

CH hex size: 19mm JIC: 1/2-20 BSPP: 1/4-19 Material: Steel

-04 BSPP O-RING MALE X -06 JIC MALE

CH hex size: 19mm JIC: 9/16-18 BSPP: 1/4-19 Material: Steel

-04 BSPP O-RING MALE X -08 JIC MALE

CH hex size: 22mm JIC: 3/4-16 BSPP: 1/4-19 Material: Steel

-04 BSPP O-RING MALE X -04 BSP MALE

Hex size: 19mm BSPP: 1/4-19 BSP: ¼-19 L1: 11.5mm L2: 12.5mm Minimum bore: 6.5mm Material: Steel

-04 BSPP O-RING MALE X -04 ORFS MALE

BSPP: 1/4-19 ORFS: 9/16-18 Material: Steel Seal material: Buna-N (nitrile)

-04 BSPP O-RING MALE X -06 ORFS MALE

BSPP: 1/4-14 ORFS: 11/16-16 Material: Steel Seal material: Buna-N (nitrile)
