90° Live Swivels

-12 NPT LIVE SWIVEL MALE X -12 NPT FEMALE 90°

Barrel connector: Female NPT Barrel connector size: -12 (3/4”) Stem connector: Male NPT Stem connector size: -12 (3/4”) T1: 3/4-14 (NPTF) T2: 3/4-14 (NPTF) A: 3.4” (86.4 mm) B: 2.36” (59.9

-12 ORB LIVE SWIVEL MALE X -08 ORFS MALE 90°

Barrel connector: Male ORFS Barrel connector size: -08 (1/2”) Stem connector: Male ORB Stem connector size: -12 (3/4”) T1: 13/16-16 (UN-2A) T2: 1-1/16-12 (UN-2A) A: 3” (76.2 mm) B: 2.16” (

-12 ORB LIVE SWIVEL MALE X -12 JIC MALE 90°

Barrel connector: Male JIC Barrel connector size: -12 (3/4”) Stem connector: Male ORB Stem connector size: -12 (3/4”) T1: 1-1/16-12 (UNF-2A) T2: 1-1/16-12 (UNF-2A) A: 3.37” (85.6 mm) B: 2.33&rdq

-12 ORB MALE LIVE SWIVEL X -12 NPSM FEMALE 90°

-12 ORFS LIVE SWIVEL MALE X -12 ORFS FEMALE 90°

Barrel connector: Male ORFS Barrel connector size: -12 (3/4”) Stem connector: Female ORFS Stem connector size: -12 (3/4”) T1: 1-3/16-12 (UN-2A) T2: 1-3/16-12 (UN-2B) A: 2.92” (74.2 mm) B: 1.88&r

-16 JIC LIVE SWIVEL MALE X -16 JIC FEMALE 90°

Barrel connector: Male JIC Barrel connector size: -16 (1”) Stem connector: Male JIC Stem connector size: -16 (1”) T1: 1-5/16-12 (UN-2A) T2: 1-5/16-12 (UN-2A) A: 3.82” (97 mm) B: 2.68” (68.

-16 NPT LIVE SWIVEL FEMALE X -16 JIC MALE 90°

Barrel connector: JIC male Barrel connector size: -16 (1") Stem connector: NPT female Stem connector size: -16 (1") T1: 1-5/16-12 T2: 1-11-1/2 A: 86.4mm (3.4") B: 57.4mm (2.26")

-16 NPT LIVE SWIVEL MALE X -16 JIC MALE 90°

Barrel connector: Male JIC Barrel connector size: -16 (1”) Stem connector: Male NPT Stem connector size: -16 (1”) T1: 1-5/16-12 (UN-2A) T2: 1-11.5 (NPTF) A: 3.82” (97.0 mm) B: 2.68” (68.1m

-16 NPT LIVE SWIVEL MALE X -16 NPSM FEMALE 90°

Barrel connector: Female NPT Barrel connector size: -16 (1”) Stem connector: Male NPT Stem connector size: -16 (1”) T1: 1-11.5 (NPSM) T2: 1-11.5 (NPTF) A: 3.82” (97 mm) B: 2.68” (68.1mm)

-16 NPT LIVE SWIVEL MALE X -16 NPT FEMALE 90°

Barrel connector: Female NPT Barrel connector size: -16 (1”) Stem connector: Male NPT Stem connector size: -16 (1”) T1: 1-11.5 (NPTF) T2: 1-11.5 (NPTF) A: 3.82” (97 mm) B: 2.68” (68.1mm)

-16 ORB LIVE SWIVEL MALE X -16 JIC MALE 90°

Barrel connector: Male JIC Barrel connector size: -16 (1”) Stem connector: Male ORB Stem connector size: -16 (1”) T1: 1-5/16-12 (UNF-2A) T2: 1-5/16-12 (UNF-2A) A: 3.62” (91.9 mm) B: 2.48”

-16 ORB MALE LIVE SWIVEL X -16 NPSM FEMALE 90°

Barrel connector: Female pipe union BC size: -16 (1”) Stem connector: Male O-ring boss SC size: -16 (1”) T1: 1-11.5” (NPSM) T2: 1-5/16-12 (UN-2A) A: 3.62” (91.9mm) B: 2.48” (63.0mm)<
